hydraulic cylinders

Depending on the requirements in terms of accuracy, servo cylinders are used with two construction designs, which differ in terms of the bearing of the piston and piston rod. 1. Cylinder with hydrostatic bearing 2. Cylinder with contact seals,which must have a particularly low level of friction. These special seals are normally made of Teflon. Servo cylinders, together with the load, form a system capable of oscillation with a relatively low natural frequency and very low damping, between 0.05 and 0.2. Hydraulic Cylinders are offered with a complete range of fluid power products making Hydropower a “Single Source Supplier“ for your complete Hydraulic requirements and thereby ensuring a SINGLE SOURCE RESPONSIBILITY. BARRELS:Hydropower hydraulic cylinder barrels are made from the imported Cold Drown Seamless Steel Pipes for reliable long life performance. SEALS:The seals are critical components of the hydraulic cylinders. Hydropower hydraulic cylinders are provided with Unique Piston Rings. For the static holding applications, special static pressure energized seals are provided, which offer positive sealing and maintenance free operation. PISTON RODS:Piston rods are made of Medium Carbon Steel and are Hard-Chrome Plated and Ground to provide a smooth, hard and scratch resistant surface for long life trouble free operation. PISTONS:One -piece, wide surface pistons of Hydropower hydraulic cylinders are made of special grade fine grained Cont. Cast Iron to withstand the heavy bearing loads, wear and impact during the operation of the cylinders.

Hydropower Engineering Systems offers high-performance Telescopic Cylinders, also known as multistage hydraulic cylinders, designed for applications requiring long stroke lengths within limited installation space. These cylinders consist of multiple nested stages—up to six—allowing extended reach while maintaining a compact retracted size. Available in both single acting and double acting configurations, telescopic cylinders provide flexibility and efficiency for various industrial needs. Engineered for durability, smooth operation, and high load capacity, they are widely used in applications such as cranes, forklifts, and other lifting equipment. With their ability to deliver long extension and reliable performance in confined areas, Hydropower telescopic cylinders are an ideal solution for demanding hydraulic operations.

Hydropower Engineering Systems offers robust and high-performance High Tonnage Hydraulic Cylinders designed to deliver exceptional linear force for heavy-duty industrial applications. These cylinders convert hydraulic fluid power into powerful linear motion, making them ideal for demanding operations in heavy engineering and industrial machinery. Available in both single acting and double acting configurations, our cylinders provide flexibility based on application requirements, with options including single rod and double rod designs for enhanced performance. Engineered for strength, precision, and durability, high tonnage cylinders are capable of generating extremely large forces, ensuring reliable operation even under high load conditions. Built with superior materials and advanced manufacturing standards, Hydropower cylinders are ideal for applications requiring high force output, consistent performance, and long service life in challenging environments.
